The control console features a membrane multi-function keypad and easy to read backlit LCD to display load and extension information. The LS1 machine can be used in stand alone mode using an optional control console or with a PC or laptop and our acclaimed NEXYGENPlus analysis software. An additional benefit is that the number of load cells required to cover the full force range may be reduced, saving the user both time in changing over different value loadcells when testing samples of different forces and also the cost of purchasing different capacity loadcells.
A load accuracy of +/- 0.5% down to 1% of loadcell value provides high dynamic range. Tension and compression testing with cycling to load and extension limits are standard features. The machine uses high accuracy interchangeable XLC Series load cells. The LS1 features unprecedented load accuracy. This means faster testing and improved productivity Combined, these new features ensure that the machine performs with the highest precision for high accuracy displacement measurement even at very slow speeds and the smallest of movements.Ĭompared to other models, the new LS1 offers an impressive speed range of 0.01-2032 mm/min. The machine has been designed with modern linear guide technology as well as pre-loaded ball screws and advanced software compensation systems. Refer to software section to view information on the Nexygen Plus software package.
Grips and load cells need to be ordered seperately. Note: Pictured with handheld console (standard) and optional PC. The new LS1 is an affordable high precision solution for materials testing applications up to 1 kN / 225 lbf capacity which, when combined with our extensive range of grips, fixtures, extensometers and software to match your application, creates a powerful new generation materials testing system.
